• Ergonomic and lightweight design of Starpen for ease of use and handling
• All types of dental anaesthesia can be administered like nerve blocks (UNIQUE ASPIRATION MODE), infiltration and intra-ligamentary.
• Compatible with the needle of your choice 30 or 27 gauge - Works with all standard anaesthetic cartridges and dental needles
• No proprietary consumables - no new running costs for use. The cartridge holders are autoclavable and will last up to 1,000 cycles per testing.
• Cordless and battery-operated without a foot pedal or console to control
• 2 modes (Auto aspiration and Manual aspiration)
• No special training is needed. Intuitive one-button aspiration is easy to set your desired injection preferences.

• 3 speed modes: High Speed, Medium Speed, Low Speed
• 2 aspiration modes: Auto aspiration, Manual aspiration The cartridge holder can be autoclaved thousands of times More cost-efficient
• Lithium battery in charging base: 3.7V /2000mAh
• Lithium battery in handpiece: 3.7V /200mAh
• Input Power: ~100V-240V 50Hz/60Hz 0.4A Max
• Output Power: DC5V/1A
• Environment temperature: +5℃ ~ +40℃
• Relative humidity: 30% ~ 75%
• Atmospheric pressure: 70kPa ~ 106kPa

• 1x Charging base
• 1x Handpiece
• 8x Autoclavable Cartridge Holder
• 1x Power adapter
• 1x Instructional Manual

Preparation:

• Ensure the Starpen is fully charged
• Check that the handpiece and cartridge holder are securely attached.

Loading the Cartridge:

• Select the appropriate local anaesthetic cartridge for the procedure.
• Remove the protective cap from the cartridge and insert it into the cartridge holder of the Star Pen.
• Ensure the cartridge is properly aligned and securely attached.

Adjusting the Injection Speed:

• The Starpen typically offers three adjustable injection speed modes. Choose the appropriate speed for the procedure.
• Use the control buttons or switches on the pen to adjust the injection speed according to your preference.

Locating the Injection Site:

• Identify the target area where the local anaesthetic needs to be administered.
• Ensure the area is clean and prepped according to standard protocols.

Administering the Local Anaesthetic:

• Hold the Starpen in a comfortable grip, ensuring a firm and stable hand position.
• Position the needle tip at the desired injection site and apply gentle pressure to initiate the injection.
• Maintain a steady hand and gradually apply the local anaesthetic using the desired injection technique (e.g., slow push, incremental injections, etc.).

Monitoring and Adjusting:

• Observe the patients response and adjust the injection speed or technique if necessary.
• Continuously monitor the patients comfort level and adjust the injection accordingly.

Post-Injection Care:

• Once the local anaesthetic has been administered, carefully remove the needle from the injection site.
• Follow proper disposal procedures for used cartridges and needles.
• Provide post-injection instructions to the patient as needed

• Country of Origin: PRC
• Manufacturer: Woodpecker

• Manufacturer/Importer warranty for Woodpecker Star Pen is 1 year.
